Triple Clamp Set, CNC Silver, Race, NX5 Forks to fit NSR250 MC21/28

CNC machined TYGA triple clamp set for the MC21 to take Honda RS250 NX5 forks.

Designed and machined in-house by TYGA from aircraft spec 6061-T6 alloy, and anodized clear. FEA tested and developed for increased strength without unnecessary weight increase.

This triple clamp set is delivered ready to fit with all necessary bearings and lower seal, and even an aluminium top clamp nut, to complete the transformation.

The Steering stoppers are reversible, giving maximum steering lock for street application, or a reduced angle for racing.

There is no provision for the ignition switch, so an alternative mounting location must be found.

• Pitch of forks: 200mm (Same as RS250)
• Fork Offset: 35mm (Same as NSR250)
• Top Clamp: 50mm Bore
• Bottom Clamp: 54mm Bore

Tightening recommendations:

• Lower clamp pinch bolts: 23Nm.
• Top clamp pinch bolts: 23Nm.
